Non Oriented Electrical Steel
Non oriented electrical steel is a silicon iron soft magnetic alloy with very low carbon content, and is an indispensable and important material in power, electronics, and military industries. With the development of high-speed and miniaturization of motors, higher requirements have been put forward for the performance of non oriented silicon steel, such as low iron loss and high magnetic induction strength at high frequencies.
| AISI | ASTM | Thickness | Max W/LB |
| M12 | 36F130 | 0.0140 | 1.30 |
| M15 | 36F145 | 0.0140 | 1.45 |
| 47F160 | 0.0185 | 1.60 | |
| M19 | 36F155 | 0.0140 | 1.55 |
| 47F165 | 0.0185 | 1.65 | |
| 64F200 | 0.0250 | 2.00 | |
| M22 | 36F165 | 0.0140 | 1.65 |
| 47F180 | 0.0185 | 1.80 | |
| 64F210 | 0.0250 | 2.10 | |
| M27 | 36F175 | 0.0140 | 1.75 |
| 47F200 | 0.0185 | 1.90 | |
| 64F235 | 0.0250 | 2.25 | |
| M36 | 36F185 | 0.0140 | 1.85 |
| 47F200 | 0.0185 | 2.00 | |
| 64F235 | 0.0250 | 2.35 | |
| M43 | 36F195 | 0.0140 | 1.95 |
| 47F210 | 0.0185 | 2.10 | |
| 64F250 | 0.0250 | 2.50 |
| Category | Silicon Content/% | Nominal Thickness/Mm | Lord To Use Way | ||
Hot Rolled Silicon Steel (No Orientation) | Hot rolled low silicon steel(Motor Steel) | 1.0~2.5 | 0.5 | Household motors and micromotors | |
Hot rolled high silicon steel(Transformer steel) | 3.0~4.5 | 0.35,0.50 | Transformer | ||
Cold Rolled Electrical Steel | Cold rolled non-oriented electrical steel(Motor Steel) | Low carbon electrical steel | ≤ 0.5 | 0.50,0.65 | Small transformers and ballasts for household motors, micromotors |
Silicon steel | >0.5~3.5 | 0.35,0.50 | Medium and large motors, generators and transformers | ||
Cold rolled grain oriented silicon steel(Transformer steel) | Ordinary oriented silicon steel | 2.9~3.3 | 0.18,0.23,0.27 | Large, medium and small transformers and ballasts | |
High magnetic induction oriented silicon steel | |||||
Special Purpose Silicon Steel | Cold rolled grain oriented silicon steel strip | 2.9~3.3 | 0.03,0.05,0.10 | Pulse transformer, magnetic amplifier, high frequency transformer and electric welding machine | |
Cold rolled non-oriented silicon steel strip | 3.0 | 0.15,0.20 | High-frequency motors and generators | ||
Cold rolled non-oriented silicon steel for magnetic switch | 3.0 | 0.70 | Relays and magnetic switches | ||
Cold rolled high silicon steel | 6.5 | 0.1~0.5 | High-frequency motors, transformers and magnetic shielding | ||
